WPF Data Binding Tutorial
 | WPF Databinding Tutorial Watch the screencast for this tutorial/post here. |
As promised, I am posting the code and explanation of the WPF Data Binding example I showed at the "Introduction to Windows Presentation Foundation" NED.NET user group event this Saturday.
A developer typically creates a class to represent an entity (table) in the database, whereby CRUD operations are performed by calling methods on the objects, e.g; for class
Employee, objEmployee.Save(), objEmployee.Load(), objEmployee.Update(), objEmployee.Delete() etc. Also, everytime the values in the object change, the developer has to manually write code to update each of the UI elements that display the values stored in the object's members. The same holds true when the values on the UI change. With WPF, you can lessen your code greatly by binding the object directly with the UI (each of object's members data-bound to individual UI elements) using XAML syntax. I will be covering 3 different approaches for displaying data in the object onto the UI.- Typical
- Using only C# [
INotifyPropertyChanged] - Using C# and XAML [
INotifyPropertyChangedand XAML]
I am going to use the same "Examinee" table I used at several demos earlier this year for the HEC (Higher Education Commission) Web Service example. The columns for the table are
- RollNo (PK, nvarchar(5), not null)
- FirstName (nvarchar(10), not null)
- LastName (nvarchar(10), not null)
- University (nvarchar(50), not null)
- MarksObtained (int, not null)
- Exam (nvarchar(15), not null)
Typical Approach
The following provides a glimpse of what goes on in code with the typical approach. The developer creates the
Examinee class for the table as follows: [For clarity, code has been colored and lines numbered. Also, ignore the SqlDataReader use for fetching a single row; it was done to lessen code ;)]
// =========================
// Code Listing 1
// =========================
1: using System;
2: using System.Collections.Generic;
3: using System.Text;
4: using System.Data;
5: using System.Data.SqlClient;
6:
7: namespace Demos.WPF.Binding.PropertyChangeNotNotified
8: {
9: class Examinee
10: {
11: private string _RollNo;
12: public string RollNo
13: {
14: get { return _RollNo; }
15: set { _RollNo = value; }
16: }
17:
18: private string _FirstName;
19: public string FirstName
20: {
21: get { return _FirstName; }
22: set { _FirstName = value; }
23: }
24:
25: private string _LastName;
26: public string LastName
27: {
28: get { return _LastName; }
29: set { _LastName = value; }
30: }
31:
32: private string _University;
33: public string University
34: {
35: get { return _University; }
36: set { _University = value; }
37: }
38:
39: private int _MarksObtained;
40: public int MarksObtained
41: {
42: get { return _MarksObtained; }
43: set { _MarksObtained = value; }
44: }
45:
46: private string _Exam;
47: public string Exam
48: {
49: get { return _Exam; }
50: set { _Exam = value; }
51: }
52:
53: public Examinee()
54: {
55: }
56:
57: public void Load()
58: {
59: if (_RollNo.Trim().Length == 0)
60: throw new Exception("Roll Number not specified.");
61:
62: SqlConnection oConnection = new SqlConnection([...]);
63: oConnection.Open();
64:
65: string str = "";
66: str += "SELECT * ";
67: str += "FROM Examinee ";
68: str += "WHERE RollNo = @RollNo";
69: SqlCommand oCommand = new SqlCommand(str, oConnection);
70: oCommand.CommandType = CommandType.Text;
71: oCommand.Parameters.Add(new SqlParameter("@RollNo", _RollNo));
72: SqlDataReader oDR = oCommand.ExecuteReader();
73:
74: if (oDR.Read())
75: {
76: _FirstName = oDR["FirstName"].ToString();
77: _LastName = oDR["LastName"].ToString();
78: _University = oDR["University"].ToString();
79: _MarksObtained = Convert.ToInt32(oDR["MarksObtained"]);
80: _Exam = oDR["Exam"].ToString();
81: }
82:
83: oCommand.Dispose();
84: oConnection.Close();
85: oConnection.Dispose();
86: }
87:
88: public void Update()
89: {
90: if (_RollNo.Trim().Length == 0)
91: throw new Exception("Roll Number not specified.");
92:
93: SqlConnection oConnection = new SqlConnection("[...]");
94: oConnection.Open();
95:
96: string str = "";
97: str += "UPDATE Examinee ";
98: str += "SET FirstName = @FirstName, ";
99: str += "LastName = @LastName, ";
100: str += "University = @University, ";
101: str += "MarksObtained = @Marks ";
102: SqlCommand oCommand = new SqlCommand(str, oConnection);
103: oCommand.CommandType = CommandType.Text;
104: oCommand.Parameters.Add(new SqlParameter("@FirstName", _FirstName));
105: oCommand.Parameters.Add(new SqlParameter("@LastName", _LastName));
106: oCommand.Parameters.Add(new SqlParameter("@University", _University));
107: oCommand.Parameters.Add(new SqlParameter("@Marks", _MarksObtained));
108: oCommand.Parameters.Add(new SqlParameter("@RollNo", _RollNo));
109: oCommand.ExecuteNonQuery();
110:
111: oCommand.Dispose();
112: oConnection.Close();
113: oConnection.Dispose();
114: }
115: }
116: }
I figured that since it is XAML that we are demonstrating, might as well develop the UI in Microsoft Cider, the Visual Studio 2005 add-in visual designer for XAML. So, to use the above class, the UI would be something like this.
The resulting XAML for the window shown above is
<!--
=========================
Code Listing 2
Simple.xaml
=========================
-->
<Window
x:Class="Demos.WPF.Binding.Simple"
xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
Title="Demos.WPF.Binding" Height="209" Width="371"
Background="WhiteSmoke" WindowStartupLocation="CenterScreen">
<Grid>
<Label
VerticalAlignment="Top"
HorizontalAlignment="Left"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="21.37,23,0,0"
Width="76.63"
Height="23.2766666666667"
Name="label1">Roll Number:</Label>
<Label
VerticalAlignment="Top"
HorizontalAlignment="Left"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="20.37,42.7233333333333,0,0"
Width="76.63"
Height="23.2766666666667"
Name="label2">First Name:</Label>
<Label
VerticalAlignment="Top"
HorizontalAlignment="Left"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="20.37,66,0,0"
Width="75.63"
Height="23.2766666666667"
Name="label3">Last Name:</Label>
<Label
VerticalAlignment="Top"
HorizontalAlignment="Left"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="21.37,89,0,0"
Width="62.63"
Height="23.2766666666667"
Name="label4">University:</Label>
<Label
VerticalAlignment="Top"
HorizontalAlignment="Left"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="21.37,112.723333333333,0,0"
Width="62.63"
Height="23.276666666666671"
Name="label5">Marks:</Label>
<TextBox
VerticalAlignment="Top"
HorizontalAlignment="Stretch"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="134,23,56,0"
Width="NaN"
Height="20"
Name="txtRollNo"
BorderBrush="#FF000000"
Foreground="#FF336699"></TextBox>
<TextBox
VerticalAlignment="Top"
HorizontalAlignment="Stretch"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="134,46,56,0"
Width="NaN"
Height="20"
Name="txtFirstName"
Foreground="#FF336699"
BorderBrush="#FF000000"></TextBox>
<TextBox
VerticalAlignment="Top"
HorizontalAlignment="Stretch"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="134,69.2766666666667,56,0"
Width="NaN"
Height="20"
Name="txtLastName"
Foreground="#FF336699"
BorderBrush="#FF000000"></TextBox>
<TextBox
VerticalAlignment="Top"
HorizontalAlignment="Stretch"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="134,92.2766666666667,56,0"
Width="NaN"
Height="20"
Name="txtUniversity"
Foreground="#FF336699"
BorderBrush="#FF000000"></TextBox>
<TextBox
VerticalAlignment="Top"
HorizontalAlignment="Stretch"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="134,114,56,0"
Width="NaN"
Height="20"
Name="txtMarks"
Foreground="#FF336699"
BorderBrush="#FF000000"></TextBox>
<Button
VerticalAlignment="Bottom"
HorizontalAlignment="Left"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="134,0,0,11"
Width="51"
Height="23"
Name="btnLoad"
Click="btnLoad_Click">Load</Button>
<Button
VerticalAlignment="Bottom"
HorizontalAlignment="Right"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="0,0,128.5625,11"
Width="48.4375"
Height="23"
Name="btnUpdate"
Click="btnUpdate_Click">Update</Button>
<Button
VerticalAlignment="Bottom"
HorizontalAlignment="Right"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="0,0,56,11"
Width="55"
Height="23"
Name="btnCheck"
Click="btnCheck_Click">Check</Button>
<Button
VerticalAlignment="Top"
HorizontalAlignment="Right"
Grid.Column="0"
Grid.ColumnSpan="1"
Grid.Row="0"
Grid.RowSpan="1"
Margin="0,115,12,0"
Width="39"
Height="19"
Name="btnAddTen"
Click="btnAddTen_Click">+10</Button>
</Grid>
</Window>
The app lets the user enter the Roll Number for a student, and dislays the Examinee's stats when the "Load" button is clicked. The user can then make any changes in values if required (except for the Roll Number), and click "Update" to make the changes in the database. Nothing fancy here. The code-behind file is pretty straight-forward as well. I have placed a "Check" button on the form to let the user view and compare the values in both, the
Examinee object and on the UI.
// =========================
// Code Listing 3
// Simple.xaml.cs
// =========================
1: using System;
2: using System.Windows;
3: using System.Windows.Controls;
4: using System.Windows.Data;
5: using System.Windows.Documents;
6: using System.Windows.Media;
7: using System.Windows.Media.Imaging;
8: using System.Windows.Shapes;
9: using Demos.WPF.Binding.PropertyChangeNotNotified;
10:
11: namespace Demos.WPF.Binding
12: {
13: public partial class Simple : Window
14: {
15: Examinee oExaminee = new Examinee();
16:
17: public Simple()
18: {
19: InitializeComponent();
20: }
21:
22: private void btnLoad_Click(object sender, EventArgs e)
23: {
24: try
25: {
26: oExaminee.RollNo = txtRollNo.Text;
27: oExaminee.Load();
28:
29: // tedious code to update UI with object's properties
30: txtFirstName.Text = oExaminee.FirstName;
31: txtLastName.Text = oExaminee.LastName;
32: txtUniversity.Text = oExaminee.University;
33: txtMarks.Text = oExaminee.MarksObtained.ToString();
34: }
35: catch (Exception oEx)
36: {
37: MessageBox.Show(oEx.Message);
38: }
39: }
40:
41: private void btnUpdate_Click(object sender, EventArgs e)
42: {
43: try
44: {
45: // tedious code to set object's properties from UI elements
46: oExaminee.FirstName = txtFirstName.Text;
47: oExaminee.LastName = txtLastName.Text;
48: oExaminee.University = txtUniversity.Text;
49: oExaminee.MarksObtained = Convert.ToInt32(txtMarks.Text);
50:
51: oExaminee.Update();
52: MessageBox.Show("Information Updated.", "Update");
53: }
54: catch (Exception oEx)
55: {
56: MessageBox.Show(oEx.Message);
57: }
58: }
59:
60: private void btnCheck_Click(object sender, EventArgs e)
61: {
62: string str = string.Format("OBJECT:\nFirstName: {0}"
63: + "\nLastName: {1}"
64: + "\nUniversity: {2}"
65: + "\nMarksObtained: {3}"
66: + "\n\nUI:"
67: + "\nFirst Name: {4}"
68: + "\nLast Name: {5}"
69: + "\nUniversity: {6}"
70: + "\nMarksObtained: {7}",
71: oExaminee.FirstName,
72: oExaminee.LastName,
73: oExaminee.University,
74: oExaminee.MarksObtained.ToString(),
75: txtFirstName.Text,
76: txtLastName.Text,
77: txtUniversity.Text,
78: txtMarks.Text);
79: MessageBox.Show(str);
80: }
81:
82: private void btnAddTen_Click(object sender, EventArgs e)
83: {
84: if ((oExaminee.MarksObtained + 10) > 100)
85: oExaminee.MarksObtained = 100;
86: else
87: oExaminee.MarksObtained += 10;
88: }
89:
90: }
91: }
Notice that in the event handlers for both, the "Load" (lines 29 to 33) and "Update" (lines 45 to 49) buttons, the values need to be shuttled between the object and the UI elements to keep them synchronized. If the form had, lets say, 30+ UI elements, the developer would have to write atleast 60 additional lines of code to achieve this synchronization. Ironically, this is what usually happens.
Using only C# [
INotifyPropertyChanged]The typical approach is pretty cumbersome. The same result can be achieved by implementing the INotifyPropertyChanged interface in the
Examinee class to generate an event everytime the value in the object's property changes. I have highlighted portions in code listing 4 that need to be added to implement INotifyPropertyChanged.
// =========================
// Code Listing 4
// =========================
1: using System;
2: using System.Collections.Generic;
3: using System.Text;
4: using System.Data;
5: using System.Data.SqlClient;
6: using System.ComponentModel;
7:
8: namespace Demos.WPF.Binding.PropertyChangeNotified
9: {
10: class Examinee : INotifyPropertyChanged
11: {
12: private string _RollNo;
13: public string RollNo
14: {
15: get { return _RollNo; }
16: set
17: {
18: _RollNo = value;
19: // Notify Property Change
20: OnPropertyChanged("RollNo");
21: }
22: }
23:
24: private string _FirstName;
25: public string FirstName
26: {
27: get { return _FirstName; }
28: set
29: {
30: _FirstName = value;
31: // Notify Property Change
32: OnPropertyChanged("FirstName");
33: }
34: }
35:
36: private string _LastName;
37: public string LastName
38: {
39: get { return _LastName; }
40: set
41: {
42: _LastName = value;
43: // Notify Property Change
44: OnPropertyChanged("LastName");
45: }
46: }
47:
48: private string _University;
49: public string University
50: {
51: get { return _University; }
52: set
53: {
54: _University = value;
55: // Notify Property Change
56: OnPropertyChanged("University");
57: }
58: }
59:
60: private int _MarksObtained;
61: public int MarksObtained
62: {
63: get { return _MarksObtained; }
64: set
65: {
66: _MarksObtained = value;
67: // Notify Property Change
68: OnPropertyChanged("MarksObtained");
69: }
70: }
71:
72: private string _Exam;
73: public string Exam
74: {
75: get { return _Exam; }
76: set
77: {
78: _Exam = value;
79: // Notify Property Change
80: OnPropertyChanged("Exam");
81: }
82: }
83:
84: public Examinee()
85: {
86: }
87:
88: public void Load()
89: {
90: if (_RollNo.Trim().Length == 0)
91: throw new Exception("Roll Number not specified.");
92:
93: SqlConnection oConnection = new SqlConnection([...]);
94: oConnection.Open();
95:
96: string str = "";
97: str += "SELECT * ";
98: str += "FROM Examinee ";
99: str += "WHERE RollNo = @RollNo";
100: SqlCommand oCommand = new SqlCommand(str, oConnection);
101: oCommand.CommandType = CommandType.Text;
102: oCommand.Parameters.Add(new SqlParameter("@RollNo", _RollNo));
103: SqlDataReader oDR = oCommand.ExecuteReader();
104:
105: if (oDR.Read())
106: {
107: _FirstName = oDR["FirstName"].ToString();
108: _LastName = oDR["LastName"].ToString();
109: _University = oDR["University"].ToString();
110: _MarksObtained = Convert.ToInt32(oDR["MarksObtained"]);
111: _Exam = oDR["Exam"].ToString();
112:
113: // following code raises onPropertyChanged event because
114: // properties are being set from within the class itself.
115: OnPropertyChanged("FirstName");
116: OnPropertyChanged("LastName");
117: OnPropertyChanged("University");
118: OnPropertyChanged("MarksObtained");
119: OnPropertyChanged("Exam");
120: }
121:
122: oCommand.Dispose();
123: oConnection.Close();
124: oConnection.Dispose();
125: }
126:
127: public void Update()
128: {
129: if (_RollNo.Trim().Length == 0)
130: throw new Exception("Roll Number not specified.");
131:
132: SqlConnection oConnection = new SqlConnection("[...]");
133: oConnection.Open();
134:
135: string str = "";
136: str += "UPDATE Examinee ";
137: str += "SET FirstName = @FirstName, ";
138: str += "LastName = @LastName, ";
139: str += "University = @University, ";
140: str += "MarksObtained = @Marks ";
141: SqlCommand oCommand = new SqlCommand(str, oConnection);
142: oCommand.CommandType = CommandType.Text;
143: oCommand.Parameters.Add(new SqlParameter("@FirstName", _FirstName));
144: oCommand.Parameters.Add(new SqlParameter("@LastName", _LastName));
145: oCommand.Parameters.Add(new SqlParameter("@University", _University));
146: oCommand.Parameters.Add(new SqlParameter("@Marks", _MarksObtained));
147: oCommand.Parameters.Add(new SqlParameter("@RollNo", _RollNo));
148: oCommand.ExecuteNonQuery();
149:
150: oCommand.Dispose();
151: oConnection.Close();
152: oConnection.Dispose();
153: }
154:
155: public event PropertyChangedEventHandler PropertyChanged;
156: protected void OnPropertyChanged(string propertyName)
157: {
158: if (this.PropertyChanged != null)
159: PropertyChanged(this, new PropertyChangedEventArgs(propertyName));
160: }
161: }
162: }
Changes made to class
Examinee of listing 1 are given in code listing 4 above. The INotifyPropertyChanged interface implementation allows the class to raise the PropertyChanged event everytime a property value changes. The above class can now be instanitated in the code-behind file (see code listing 5 below) of another XAML file (WithoutXAML.xaml) which is similar to that of code listing 2.
// =========================
// Code Listing 5
// WithoutXAML.xaml.cs
// =========================
1: using System;
2: using System.Windows;
3: using System.Windows.Controls;
4: using System.Windows.Data;
5: using System.Windows.Documents;
6: using System.Windows.Media;
7: using System.Windows.Media.Imaging;
8: using System.Windows.Shapes;
9: using Demos.WPF.Binding.PropertyChangeNotified;
10:
11: namespace Demos.WPF.Binding
12: {
13: public partial class WithoutXAML : Window
14: {
15: Examinee oExaminee = new Examinee();
16:
17: public Simple()
18: {
19: InitializeComponent();
20: }
21:
22: private void WithoutXAML_Load(object sender, EventArgs e)
23: {
24: oExaminee.PropertyChanged += oExaminee_PropertyChanged;
25: }
26:
27: // Property Changed Event Handler [Pathetic Code!]
28: private void oExaminee_PropertyChanged(object sender,
29: PropertyChangedEventArgs e)
30: {
31: switch(e.PropertyName)
32: {
33: case "FirstName":
34: txtFirstName.Text = oExaminee.FirstName;
35: break;
36: case "LastName":
37: txtLastName.Text = oExaminee.LastName;
38: break;
39: case "University":
40: txtUniversity.Text = oExaminee.University;
41: break;
42: case "MarksObtained":
43: txtMarks.Text = oExaminee.MarksObtained.ToString();
44: break;
45: }
46: }
47:
48: private void btnLoad_Click(object sender, EventArgs e)
49: {
50: try
51: {
52: oExaminee.RollNo = txtRollNo.Text;
53: oExaminee.Load();
54: }
55: catch (Exception oEx)
56: {
57: MessageBox.Show(oEx.Message);
58: }
59: }
60:
61: private void btnUpdate_Click(object sender, EventArgs e)
62: {
63: try
64: {
65: oExaminee.Update();
66: MessageBox.Show("Information Updated.", "Update");
67: }
68: catch (Exception oEx)
69: {
70: MessageBox.Show(oEx.Message);
71: }
72: }
73:
74: private void btnCheck_Click(object sender, EventArgs e)
75: {
76: string str = string.Format("OBJECT:\nFirstName: {0}"
77: + "\nLastName: {1}"
78: + "\nUniversity: {2}"
79: + "\nMarksObtained: {3}"
80: + "\n\nUI:"
81: + "\nFirst Name: {4}"
82: + "\nLast Name: {5}"
83: + "\nUniversity: {6}"
84: + "\nMarksObtained: {7}",
85: oExaminee.FirstName,
86: oExaminee.LastName,
87: oExaminee.University,
88: oExaminee.MarksObtained.ToString(),
89: txtFirstName.Text,
90: txtLastName.Text,
91: txtUniversity.Text,
92: txtMarks.Text);
93: MessageBox.Show(str);
94: }
95:
96: private void btnAddTen_Click(object sender, EventArgs e)
97: {
98: if ((oExaminee.MarksObtained + 10) > 100)
99: oExaminee.MarksObtained = 100;
100: else
101: oExaminee.MarksObtained += 10;
102: }
103:
104: ///////////////////////////////////
105: // WARNING: Pathetic Code below! //
106: // Event-handlers for text-boxes //
107: ///////////////////////////////////
108:
109: private void txtRollNo_TextChanged(object sender,
110: EventArgs e)
111: {
112: oExaminee.RollNo = txtRollNo.Text;
113: }
114:
115: private void txtFirstName_TextChanged(object sender,
116: EventArgs e)
117: {
118: oExaminee.FirstName = txtFirstName.Text;
119: }
120:
121: private void txtLastName_TextChanged(object sender,
122: EventArgs e)
123: {
124: oExaminee.LastName = txtLastName.Text;
125: }
126:
127: private void txtUniversity_TextChanged(object sender,
128: EventArgs e)
129: {
130: oExaminee.University = txtUniversity.Text;
131: }
132:
133: private void txtMarks_TextChanged(object sender,
134: EventArgs e)
135: {
136: int marks = 0;
137: if (int.TryParse(txtMarks.Text, out marks))
138: oExaminee.MarksObtained = marks;
139: }
140: }
141: }
Notice that the
oExaminee_PropertyChanged event handler (lines 27 to 46) updates the UI with object values everytime a PropertyChanged event occurs on the Examinee object. To update the object with UI values, TextChanged event handlers were added for all the textboxes (see lines 104 to 139).Notice also that the "Load" and "Update" button event handlers do not contain the Object-to-UI and UI-to-Object update code as that is now being handles by the event handlers.
However, just because we implemented the
INotifyPropertyChanged interface in our Examinee class, we were not absolved of the responsibility to write custom event handlers for the object and UI update logic. The whole point of all the above code is to show the tedious coding required to keep the object and UI in sync.Using C# and XAML [
INotifyPropertyChanged and XAML]Both the approaches described above were used with typical Windows applications, although I created the form using XAML. The final approach (and the right one at that) uses the Data Binding syntax in XAML, and would show you how easy it is to bind UI elements directly to an object that implements
INotifyPropertyChanged.To see WPF Data Binding in action, the Binding sytax in the textboxes' "Text" property values. The XAML file would not look something like code listing 6. [Changes from previous XAML file have been highlighted.]
<!--
=========================
Code Listing 6
WithXAML.xaml
=========================
-->
<Window
x:Class="Demos.WPF.Binding.WithXAML"
xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
Title="Binding - Using XAML Binding Syntax"
Height="209" Width="371" Background="WhiteSmoke"
WindowStartupLocation="CenterScreen" Loaded="WithXAML_Load" >
<Grid x:Name="myGrid" >
<Label ...>Roll Number:</Label>
<Label ...>First Name:</Label>
<Label ...>Last Name:</Label>
<Label ...>University:</Label>
<Label ...>Marks:</Label>
<TextBox
...
Name="txtRollNo"
Text="{Binding Path=RollNo}"></TextBox>
<TextBox
...
Name="txtFirstName"
Text="{Binding Path=FirstName}"></TextBox>
<TextBox
...
Name="txtLastName"
Text="{Binding Path=LastName}"></TextBox>
<TextBox
...
Name="txtUniversity"
Text="{Binding Path=University}"></TextBox>
<TextBox
...
Name="txtMarks"
Text="{Binding Path=MarksObtained}"></TextBox>
<Button ...>Load</Button>
<Button ...>Update</Button>
<Button ...>Check</Button>
<Button ...>+10</Button>
</Grid>
</Window>
The Binding statement added to the XAML above allows you to discard all the event-handlers in the code-behind that were needed before. The function that we wanted from our app is now achievable with a lot less code.
// =========================
// Code Listing 7
// WithXAML.xaml.cs
// =========================
1: using System;
2: using System.Windows;
3: using System.Windows.Controls;
4: using System.Windows.Data;
5: using System.Windows.Documents;
6: using System.Windows.Media;
7: using System.Windows.Media.Imaging;
8: using System.Windows.Shapes;
9: using Demos.WPF.Binding.PropertyChangeNotified;
10:
11: namespace Demos.WPF.Binding
12: {
13: public partial class WithXAML : Window
14: {
15: Examinee oExaminee = new Examinee();
16:
17: public WithXAML()
18: {
19: InitializeComponent();
20: }
21:
22: private void WithXAML_Load(object sender, EventArgs e)
23: {
24: myGrid.DataContext = oExaminee;
25: }
26:
27: private void btnAddTen_Click(object sender, EventArgs e)
28: {
29: if ((oExaminee.MarksObtained + 10) > 100)
30: oExaminee.MarksObtained = 100;
31: else
32: oExaminee.MarksObtained += 10;
33: }
34:
35: private void btnLoad_Click(object sender, EventArgs e)
36: {
37: try
38: {
39: oExaminee.Load();
40: }
41: catch (Exception oEx)
42: {
43: MessageBox.Show(oEx.Message);
44: }
45: }
46:
47: private void btnUpdate_Click(object sender, EventArgs e)
48: {
49: try
50: {
51: oExaminee.Update();
52: MessageBox.Show("Information Updated.", "Update");
53: }
54: catch (Exception oEx)
55: {
56: MessageBox.Show(oEx.Message);
57: }
58: }
59:
60: private void btnCheck_Click(object sender, EventArgs e)
61: {
62: string str = string.Format("OBJECT:\nFirstName: {0}"
63: + "\nLastName: {1}"
64: + "\nUniversity: {2}"
65: + "\nMarksObtained: {3}"
66: + "\n\nUI:"
67: + "\nFirst Name: {4}"
68: + "\nLast Name: {5}"
69: + "\nUniversity: {6}"
70: + "\nMarksObtained: {7}",
71: oExaminee.FirstName,
72: oExaminee.LastName,
73: oExaminee.University,
74: oExaminee.MarksObtained.ToString(),
75: txtFirstName.Text,
76: txtLastName.Text,
77: txtUniversity.Text,
78: txtMarks.Text);
79: MessageBox.Show(str);
80: }
81: }
82: }
The only change occured in line 24 in the
WithXAML_Load event handler; the Examinee object was assigned to the main Grid's DataContext property. The highlighted statement in code listing 7 above defines a data context for the Grid, the UI element that encloses all the other UI controls. WPF introduces the concept of "Dependency Properties" that enables a XAML UI element to inherit a value from its parent UI control (in this case the grid). Once the data context is set in the form load event, the {Binding Path=...} statements in XAML simply retrieve the values from the bound object or resource and place them in the target textbox. If you run the application now, everytime you change the value in a textbox, the corresponding value in the object changes (You can test this by clicking the "Check" button after you update the value in a textbox). Same holds true for the object. If you click the "+10" (btnAddTen) button, the value in the object is incremented by 10. However, you will also see that the value is automatically updated in the textbox as well.Try the above, and feel free to ask any questions that you may have. I have really outdone myself with this post. I guess I am all set to write a book now.
Download source code from here.
